     Packaging application | Stamping Foil application | Metallizing application | Graphic Art application



Thickness Yield
Micron Gauge §³/kg g/§³
9 36 79.4 12.6
12 48 59.5 16.8
16 64 44.6 22.4
25 100 28.6 35.0
38 152 18.8 53.2
50 200 14.3 70.0
75 300 9.5 105.0
100 400 7.1 140.0
125 500 5.7 175.0
150 600 4.8 210.0


* THICKNESS : 12MIC, 15MIC, 16MIC, 19MIC, 23MIC, 25MIC, 36MIC, 38MIC, 50MIC, 75MIC, 100MIC, 125MIC,
                       150MIC, 175MIC, 188MIC, 250MIC, 350MIC
* WIDTH : 500MM ~ 2,100MM
- NARROW SLITTED MATERIAL WILL BE AVAILABLE( 18MM ~ 300MM)


* CORE I.D. : 76MM OR 152MM
* WIDTH : 500MM ~ 2,100MM
* OUT DIAMETER : 300 ~ 1,000MM





¡á
OHP FILM
    - A4 size & ROLL are available

¡á MATT PET FILM for DRAFTING & PLOTTER
    - 38MIC, 50MIC, 75MIC & 100MIC

¡á INKJET FILM
    - A4 size & ROLL are available
  INDUSTRIAL
    Compactness, preciseness as well as electrical properties are the prerequisites for electric components.
    Hangyo PET Film's superiority in dielectic strength, temperature stability and electrical integrity more than
    meets the electrical industry.

  GRAPHIC

   "Hangyo PET Film" has an unlimited range of uses. Its excellence in durability, dimensional stability,
   transparency and wide range of practicable temperature promises users new usages in a growing list of
   applications such as reprographic film, visual presentation film and diazo film.
