PP Deco sheet : Coated type
Print Data Sheet
Characteristic Membrane sheet has been developed in conjunction with major and specifier within the kitchen, bedroom, furniture market.
Surface finish Coated with a durable scratch resistance Laquer to provide protection against scratch, mar and stain.
Thickness range
Width & Color
0.20mm - 0.45mm
1,200mm - 1,450mm
various
Properties Test method Value Unit
Thickness allowance
0.20mm - 0.45mm
JIS K6734 ¡¾3 %
Width & length
allowance
JIS K6734 ¡¾3 mm
Density JIS K6734 1.4 g/§¨
Shrinkage
(100¡É 5minutes)
machine direction
transverse direction
KSM 3001 ¡â2.5
1
%
%
Tensile strenrgth
machine direction
transverse direction
KSM 3001 3.88
3.54
kg f/mm
kg f/mm
Tear strength
machine direction
transverse direction
KSM 3001 12.08
11.94
kg f/mm
kg f/mm
Tear strength
machine direction
transverse direction
JIS K6734 15.8
6.5
kg/mm
kg/mm
Impact strength
machine direction
transverse direction
KSM 3501 7 >
9 >
kg f/§²
kg f/§²
Elongation
machine drection
transverse direction
KSM 3001 107 >
16 >
%
%
Chemical resistance
2% NaoH
MEK
Rubbing over
20 times
No defect
No defect
No defect
No defect
Glossy grade   8-2 degree
Discoloration UV-CON
(ATLAS,USA)
1000 hrs
¡âE 1.0
-1.8
¡âE 2.5
Below
Emboss extinction 130 £§¡Æ
120 £§¡Æ¡Â
